Profile Shift – Default is 0 for most applications. To convert, use: Module = 25.4 / Diametral Pitch Module (Pitch) – this parameter sets the tooth size. The rack length defaults to the diameter of Gear 2. Gear Type – External spur gears use a positive tooth count, while internal spur gears use a negative tooth count. Tooth Count – is set with the parameter "n" for Gear 1 and Gear 2
Product design processes include the ability to generate geometry of other integrated design disciplines such as industrial and standard pipe work and complete wiring definitions.
The capabilities of the product can be split into three main groups, that is Engineering design, Analysis and Manufacturing. Companies with family-based or platform-driven product strategy make use of this approach for what they need to perform successful design processes is a prescriptive design strategy. The application is based on the parametric modeling approach, which means that it uses parameters, dimensions, features, and relationships to enable design automation and optimization of design and product development processes. Its users are mostly mechanical engineers, designers and manufacturers.
It provides solid modeling, assembly modeling, 2D orthographic views, FEA, direct and parametric modeling, sub-divisional and NURBS surface modeling, and tools for mechanical designers. PTC Creo by Parametric Technology Corporation, known as Pro/Engineer is a 3D CAD, CAM, CAE, and associative solid modeling application.
